Share with you guys my favourite engine... its not the best 1, but is a good 1...
VTEC is an acronym for Variable valve Timing and Electronic lift Control. VTEC is a valve train system developed by Honda to improve the volumetric efficiency of an 4-stroke internal combustion engine. This system uses two camshaft profiles and electronically selects between the profiles. This was the first system of its kind. Different types of variable valve timing and lift control systems have also been produced by other manufacturers.
i-VTEC (intelligent-VTEC) introduced continuously variable camshaft phasing on the intake cam of DOHC VTEC engines. The technology first appeared on Honda's K-series four cylinder engine family in 2001 (2002 in the U.S.). Valve lift and duration are still limited to distinct low and high rpm profiles, but the intake camshaft is now capable of advancing between 25 and 50 degrees (depending upon engine configuration) during operation. Phase changes are implemented by a computer controlled, oil driven adjustable cam gear. Phasing is determined by a combination of engine load and rpm, ranging from fully retarded at idle to maximum advance at full throttle and low rpm. The effect is further optimization of torque output, especially at low and midrange RPM.
For the K-Series motors there are two different types of i-VTEC systems implemented. The first is for the performance motors like in the RSX Type S or the TSX and the other is for economy motors found in the CR-V or Accord. The performance i-VTEC system is basically the same as the DOHC VTEC system of the B16A's, both intake and exhaust have 3 cam lobes per cylinder. However the valvetrain has the added benefit of roller rockers and continuously variable intake cam timing. The economy i-VTEC is more like the SOHC VTEC-E in that the intake cam has only two lobes, one very small and one larger, as well as no VTEC on the exhaust cam. The two types of motor are easily distiguishable by the factory rated power output: the performance motors make around 200 hp or more in stock form and the economy motors do not make much more than 160 hp from the factory.
An additional version of i-VTEC was introduced on the 2006 Honda Civic's R-series four cylinder SOHC engines. This implementation uses the so-called "economy cams" on one of the two intake valves of each cylinder. The "economy cams" are designed to delay the closure of the intake valve they act upon, and are activated at low rpms and under light loads. When the "economy cams" are activated, one of the two intake valves in each cylinder closes well after the piston has started moving upwards in the compression stroke. That way, a part of the mixture that has entered the combustion chamber is forced out again, into the intake manifold. That way, the engine "emulates" a lower displacement than its actual one (its operation is also similar to an Atkinson cycle engine, with uneven compression and combustion strokes), which reduces fuel consumption and increases its efficiency. During the operation with the "economy cams", the (by-wire) throttle butterfly is kept fully open, in order to reduce pumping losses. According to Honda, this measure alone can reduce pumping losses by 16%. In higher rpms and under heavier loads, the engine switches back into its "normal cams", and it operates like a regular 4 stroke Otto cycle engine. This implementation of i-VTEC was initially introduced in the R18A1 engine found under the bonnet of the 8th generation Civic, with a displacement of 1,8lt and an output of 140Ps. Recently, another variant was released, the 2-litre R20A2 with an output of 150Ps, which powers the EUDM version of the all-new CRV.
With the continued introduction of vastly different i-VTEC systems, one may assume that the term is now a catch-all for creative valve control technologies from Honda.
.jpeg)
engine for the new civic type R
